描述
Currently launched on kickstarter, and please purchase from kickstarter. www.kickstarter.com
Dimensions:
Length = 6.1 inches (15.5 cm)
Width = 4.1 inches (10.5 cm)
Height = 1.1 inches (2.8 cm)
Weight = 0.9 lb (0.4 kg)
Electrical Characteristics:
Rated Voltage = 5V-24V DC
LCD Size = 52*41 mm
Sampling Rate = 500Msps
Vertical Resolution = 10Bit/8Bit
Analog Bandwidth = DC-200MHz
Maximum Observable Frequency = 450MHz
Coupling Mode = DC/AC/GND
Cache Depth = 50KB
Input Voltage = 20Vpp (1:1 Probe)
Trigger Mode = Rising Edge & Falling Edge
Display Mode = Automatic & Single & Freeze
Signal Generator Frequency = 0.1Hz-100MHz
Signal Generator Mode = DDS&VCO
DDS Accuracy = 0.1Hz
Programmable Positive Output = +(0.1V-12V) 3W @5V 2A adapter
Programmable Negative Output = -(0.1V-12V) 1W @5V 2A adapter
Programmable Positive Output = +(0.1V-18V) 15W @19V 2A adapter
Programmable Negative Output = -(0.1V-18V) 5W @19V 2A adapter
Interfaces = USB TypeC, GPIOs, SWD, TF Card
